High-security locks
Also called: keyed patio door locks, auxiliary sliding door locks
Quick answer: high-security locks are sliding door locks made to be harder to force than a standard single hook. They include keyed locks, locks with two hooks or bolts, and add-on locks such as a foot lock, loop lock or charley bar. The add-ons give the door a second point of locking.
- Main lock, a keyed hook lock in the handle edge
- Charley bar, which folds down to stop the panel sliding
- Track bar, a bar or dowel laid in the bottom track
- Pin lock, a pin through both frames where they overlap
- Foot lock, which you step on to drop a pin into the track
Upgrading, in order
Start with the lock you have, then add a second point. Each step builds on the one before.
-
Make the main lock catchThe hook must bite the keeper fully. Adjust the keeper or the rollers if it misses.
Safe to do yourself
-
Firm up the keeperTighten its screws, and use longer ones if the old holes are stripped.
Safe to do yourself
-
Add a second pointLay a bar in the bottom track, or fit a charley bar or a foot lock.
Take care: drill frame metal only
-
Upgrade the lock itselfFit a keyed or two-hook lock that matches the pocket in your panel.
Call a pro
Fix it yourself or call a pro
- Safe yourselfA bar or dowel in the track, tightening the keeper, and testing the lock with the door open.
- Take careDrilling for a charley bar, pin lock or foot lock. Drill only through frame metal, well clear of the glass edge.
- Call a proA new keyed or multipoint lock, a pocket that needs cutting, or damage after a break-in attempt.
Step by step: sliding door won’t lock or latch? What to check.

Main lock upgrades and add-on locks
Choosing a whole new door? See which patio doors are most secure.
Want a stronger lock on your slider?
Select Sliding Doors handles sliding door repair, including lock upgrades and replacements, across Dallas-Fort Worth. Mon to Sat, 7am to 10pm.
Questions people ask
What is the most secure lock for a sliding door?
No single lock does it all. A main lock that fully catches, a second point such as a bar or foot lock, and anti-lift devices in the top track work best together.
Can I add a keyed lock to my existing door?
Often, yes. Many sliding doors can take a mortise lock with a key cylinder, if one fits the pocket. A technician can tell you what your door takes.
Is a charley bar worth it?
It is one of the simplest second locks. It folds down at mid-height to stop the door sliding, and folds up out of the way when you need the door.
