Glass and weather

Thermal break

Also called: thermally broken frame, thermal barrier

Quick answer: a thermal break is a strip of hard plastic, usually polyamide, built into an aluminum door frame. It splits the frame into an outside half and an inside half, so heat cannot flow straight through the metal.

Why aluminum needs it
Aluminum carries heat fast. Without a break, the inside of the frame gets hot in summer sun and cold on winter mornings.

Less frame sweating
A warmer inside frame means less condensation running down onto the sill and floor.

Built in, not added
It is made into the frame at the factory. An old frame without one cannot be fitted with it later.
The frame, cut through: how the break fits

OutsideInside1234

  1. Outside half, the aluminum that faces sun and weather
  2. Plastic strips, locked into grooves on both halves, the only link between them
  3. Inside half, the aluminum you touch from the room
  4. Glass unit, which sits in the frame across both halves
Because the two halves never touch, each one can be a different color.

Fix it yourself or call a pro

  • Safe yourselfWipe condensation off the frame and sill, and keep the track clean so water drains away.
  • Take careDrafts around an aluminum door are often worn weatherstripping, not the frame. Check the seals first.
  • Call a proReplacing an old aluminum door with a thermally broken one. Measuring, removing the old frame and sealing the new one is a pro job.

More on this: can you replace just the glass in a sliding door?

A bright empty room with a wall of glass doors in dark aluminum frames
Dark aluminum frames take in a lot of sun heat, so a thermal break matters most here.

Frame options compared

Aluminum, no break
Strong and slim, found on many older doors
Frame gets hot or cold and sweats on cool mornings
Thermally broken aluminum
Keeps aluminum’s strength with a much warmer inside frame
Usually the costlier aluminum option
Vinyl
Insulates on its own, no break needed
Frames are bulkier and less stiff for very large panels

Old aluminum door running hot?

Select Sliding Doors fits new energy-efficient doors with thermally broken frames through sliding door installation across Dallas-Fort Worth. Mon to Sat, 7am to 10pm.

Questions people ask

How can I tell if my aluminum door has a thermal break?

Look at the frame edges with the door open. A dark plastic band between the inside and outside metal is the break. A frame with a different color inside and out often has one too. The door’s paperwork will say “thermally broken”.

Is a thermal break worth it in Texas?

For comfort, yes. The frame by your hand stays closer to room temperature on hot afternoons, and it pairs well with Low-E glass to keep sun heat out.

Do I need a new door to get better glass?

Not always. If the frame is sound, the glass unit alone can often be swapped for an energy-efficient one. A thermal break, though, only comes with a new frame.

Related terms

Photo: own media library. Diagram: Select Sliding Doors.
